SPECIFICATIONS

Brand Name: other

Choice: yes

DIY Supplies: ELECTRICAL

Hign-concerned Chemical: None

Origin: Mainland China

• High-Precision Induced Electric Tester Pen :The electric pen is designed to provide high-precision testing, making it an accurate tool for voltage detection.

• Electroprobe Screwdriver Probe Light Voltage Tester :With its electroprobe screwdriver probe light, this test pen can easily detect voltage levels in hard-to-reach areas.

• Multi-functional :This test pen can be used for a variety of tasks, including voltage detection, electroprobing, and screwdriver probing.

• Lightweight and Portable :The compact size of this test pen makes it easy to carry around, allowing you to take it with you wherever you go.

Features

A voltage tester, also known as a voltage tester, a voltage tester, or a neon tube tester, is a safety tool used to detect whether a circuit is electrified. Its working principle is mainly to use the characteristics of electric current to discharge and emit light through neon gas to determine whether the voltage exists.

A voltage tester usually consists of a handle made of insulating material and a metal probe on the front end, which contains a neon bubble or other type of indicator light and a resistive element. When the user touches the voltage tester with a conductor that may be charged, if there is voltage in the circuit, the current will pass through the resistance of the human body, the internal resistance of the voltage tester to the neon bubble, and when the current reaches a certain value, the neon bubble will emit a red light to show that the point is charged.

When using a voltage tester, you need to pay attention to the following points:1. The gesture of holding the voltage tester should be correct, and generally use your fingers to touch the metal part of the tail of the voltage tester to provide a current loop. 2. Before measuring, confirm that the voltage tester is in good working condition and that the neon bubble can emit light normally. 3. It can only be used for the detection of AC low-voltage circuits (such as household electricity), and for high-voltage lines, special high-voltage electroscopes are required. 4. Although the voltage tester has a certain safety design, it still needs to be operated with caution and try to avoid directly touching the bare wire.

AC voltage range: default 48~1000V; High sensitivity 12~1000V

Frequency: 50Hz/60Hz

Alarm mode: sound and light alarm

Flashlight: white LED light

Auto power off: 5 minutes of no operation and no voltage signal automatic power off

Battery undervoltage indication: voltage is lower than 2.4V The power light flashes three times and beeps three times

Zero live line judgment: According to the signal strength, the strong signal is the live line

NCV sensitivity: 2 sensitivity (High/Low)

NCV sensitivity indication mode: high sensitivity when the sensitivity indicator is on,

low sensitivity test state when offOperating temperature: 0~40 degrees

Storage temperature: -10~50 degrees

Safety level: CE CAT.111000V/CAT.IV600V

Battery: Two No. 7 batteries /2*1.5VAAA(not included)

Product weight: about 52g

Note

1.Due to the difference between different monitors, the picture may not reflect the actual color of the item. We guarantee the style is the same as shown in the pictures.

2.Manual measurement may have an error of 0-1 cm.
